| Part number | 60121212C |
|---|---|
| Tensión | 12 V |
| Potencia nominal | 273 W |
| Velocidad nominal | 285 rpm |
| Combination gear ratio | 12.5:1 |
| Combination gear material | Composite |
| Nominal torque | 9.0 Nm |
| Intermittent torque | 12.2 Nm |
| Motor part number | 775166 |
| Motor type | PMDC |
| Motor voltage | 12 V |
| Motor power | 273 W |
| Motor output speed | 3000 rpm |
| Motor continuous current | 28.5 A |
| Motor no load speed | 3562 rpm |
| Motor no load current | 2.50 A |
| Motor continuous torque | 0.87 Nm |
| Motor intermittent torque | 1.15 Nm |
| Motor length (L) | 193 mm |
| Motor weight | 2.90 Kg |
| Gearbox part number | GB12-12.5C |
| Gearbox ratio | 12.5:1 |
| Gearbox orientation | Right angle |
| Gearbox type | Tornillo sin fin |
| Gearbox max continuous torque | 20.0 Nm |
| Gearbox max intermittent torque | 32.0 Nm |
| Gearbox efficiency | 85% |
| Gearbox gear material | Composite |
| Gearbox axial load | 600 N |
| Gearbox radial load | 800 N |
| Gearbox length | 110 mm |
| Gearbox weight | 1.10 Kg |
| Peso (kg) | 4.00 |
PM60 12V 3000 RPM – GB12 12.5:1 Composite
Código de producto:60121212C
L: 303.0 × W: 77.0 × H: 143.0mm
PM60 12V 3000 RPM - GB12 4:1 Composite - PMDC geared right-angle motor - 12 V - Delivers up to 12.2 Nm of torque (S2 - 15 minutes) - 4:1 gear ratio with composite gears - Standard combination - please contact your local sales engineer for details on your customisation options
The Parvalux PM60 is a permanent magnet direct current (DC) motor. It is available in a range of options with voltages from 12v - 220v DC and output power up to 273 Watts. It is rated for nominal continuous torque up to 0.87 Nm (S1) and maximum intermittent torque up to 1.15 Nm (S2-15min). This motor is perfectly suited for use with a range of Parvalux right-angle and inline gearboxes enabling you to assemble the perfect geared motor combination for your application.
